Cold Draw Seamless Boiler Tubes BS3059 Gr.360 High Pressure Boiler Steel Pipe
  • Cold Draw Seamless Boiler Tubes BS3059 Gr.360 High Pressure Boiler Steel Pipe
  • Cold Draw Seamless Boiler Tubes BS3059 Gr.360 High Pressure Boiler Steel Pipe
  • Cold Draw Seamless Boiler Tubes BS3059 Gr.360 High Pressure Boiler Steel Pipe
  • Cold Draw Seamless Boiler Tubes BS3059 Gr.360 High Pressure Boiler Steel Pipe
  • Cold Draw Seamless Boiler Tubes BS3059 Gr.360 High Pressure Boiler Steel Pipe

Cold Draw Seamless Boiler Tubes BS3059 Gr.360 High Pressure Boiler Steel Pipe

Place of Origin CHANGZHOU, CHINA
Brand Name Joyruns
Certification ISO9000
Model Number 6mm --137mm
Product Details
OD. Range:
6mm – 137mm
Wall Thickness:
1mm-20mm
Length:
Max Length 20M
Standard:
BS3059
Grade:
360, 440,243,620-460,622-490,629-470,629-590,762
Type:
Seamless Boiler Tube/heat Exchanger Tube
High Light:

20mm Seamless Boiler Tubes

,

BS3059 Seamless Boiler Tubes

,

BS 3059 Gr.360

Product Description

BS3059 Gr.360 Cold drawing High-Pressure Boiler Steel Pipe

BS 3059 II 360 requirements specification for carbon, alloy and austenitic stainless steel tubes with specified elevated temperature properties.
Boiler pipe refers to one of the seamless steel pipes. The method of manufacturing boiler tubes is the same as seamless steel pipe, but this pipe has a requirement of steel grades. Depending on the operating temperature, it can be divided into two kinds: general boiler pipes and high-pressure boiler pipes.

A general boiler pipe is able to work below the temperature 450°C. It’s made of hot-finished or cold-rolled carbon steel pipes. While high-pressure boiler tube is used to produce high-pressure or ultrahigh-pressure superheater tube, reheater tube,gas-guide tube, main steam pipe and so on. Our product BS3059-II 360 10 belongs to this boiler tube.



Specifications:



Chemical Composition(%):

Grade

C

Si

Mn

P

S

Cr

Mo

Ni

Other

360

≤0.17

0.10~0.35

0.40~0.8

≤0.035

≤0.035

-

-

-

-

440

0.12~0.18

0.10~0.35

0.90~1.2

≤0.035

≤0.035

-

-

-

-

243

0.12~0.2

0.10~0.35

0.40~0.8

≤0.035

≤0.035

-

0.25~0.35

-

Al≤0.012

620-460

0.10~0.15

0.10~0.35

0.40~0.7

≤0.030

≤0.030

0.70~1.10

0.45~0.65

-

Al≤0.02

622-490

0.08~0.15

≤0.50

0.40~0.7

≤0.030

≤0.030

2.00~2.50

0.90~1.2

-

Al≤0.02

629-470

≤0.15

0.25~1

0.3~0.6

≤0.030

≤0.030

8~10

0.9~1.1

-

Al≤0.02

629-590

762

0.17~0.23

≤0.50

≤1.00

≤0.030

≤0.030

10.00~12.5

0.80~1.2

0.30~0.8

V 0.25~0.35





Mechanical Properties:




Grade

Tensile Strength (MPa)

Yield Strength (Mpa Min)

Elongation (% Min)

Flatten Coefficient

360

360~500

235

24

0.1

440

440~580

245

21

0.07

243

480~630

275

22

0.07

620~460

460~610

180

22

0.07

622~490

490~640

275

20

0.07

629~470

470~620

185

20

0.07

629~590

590~740

400

18

0.07

762

720~870

470

15

0.08
