OD 19.05mm WT 1.65Mm BWG Seamless Titanium Pipe Shell Heat Exchanger

OD 19.05mm WT 1.65Mm BWG Seamless Titanium Pipe Shell Heat Exchanger

Product Details:

Place of Origin: Changzhou
Brand Name: Joyruns
Certification: ISO9001
Model Number: 19.05*1.65mm

Payment & Shipping Terms:

Minimum Order Quantity: 500KG
Packaging Details: wooden box packing
Delivery Time: 30days
Payment Terms: L/C, T/T
Supply Ability: 2000Tons/Month
Get Best Price Contact Now

Detail Information

Standard: ASTM B338 ASTM B337 ASTM B862 ASTM B861 Material: GR.1, GR.2
Type: Seamless/ERW OD: 2mm To 219mm
WT: 0.5MM To 20MM Length: 12M
High Light:

BWG Seamless Titanium Pipe

,

WT 1.65Mm Seamless Titanium Pipe

,

Heat Exchanger Annealed Tube

Product Description

OD 19.05 WT 1.65 Mm BWG Seamless Titanium Pipe Shell Heat Exchanger Annealed Tube

Seamless and Welded Titanium Tubes are essential tubing bundle materials for industrial shell and tube-type heat exchangers. It helps to transfer heat from one to another fluid, nice working performance during high temperature and pressure, heat exchangers are kinds of two types, U titanium tube heat exchangers and straight titanium tube heat exchangers tubes.



ASTM B338 Gr1 Gr2 Gr9 Gr12 Titanium Heat exchanger Tubes are used for cooling, heating or re-heating of fluids, gases or air in a wide range of industries, such as chemical processing, oil refining, nuclear power generation, petrochemical and aerospace.

Material Available: Gr1, Gr2, Gr3, Gr7, Gr9, Gr11, Gr12, Gr16, Gr17, Gr26, Gr28 etc



ASTM Grade Alloy DIN UNS
Grade 1 Commercially pure 3.7025 R50250
Grade 2 Commercially pure 3.7035 R50400
Other grade and alloy are available by request



Dimension:



  Out diameter Wall thickness Length
Seamless 2.0 ~ 114 mm 0.3 ~ 8.0 mm Up to 18000 mm
Welded 89 ~ 1000 mm 2.0 ~ 15.0 mm By request



Chemical Composition of ASME SB337 Ti Seamless Pipe

Grade C N O H Ti V Al Fe
Titanium Grade 1 .08 Max .03 Max .18 Max .015 Max Bal     .20 Max
Titanium Grade 2 0.1 max 0.03 max 0.25 max 0.015 max 99.2 min     0.3 max



Physical properties



Grade Tensile Strength (min) Yeild strength (min) Elongation(%)
Ksi MPa Ksi MPa
Gr.1 35 240 20 138 24
Gr.2 50 345 40 275 20





Plant

OD 19.05mm WT 1.65Mm BWG Seamless Titanium Pipe Shell Heat Exchanger 0  OD 19.05mm WT 1.65Mm BWG Seamless Titanium Pipe Shell Heat Exchanger 1  OD 19.05mm WT 1.65Mm BWG Seamless Titanium Pipe Shell Heat Exchanger 2



Packing

OD 19.05mm WT 1.65Mm BWG Seamless Titanium Pipe Shell Heat Exchanger 3  OD 19.05mm WT 1.65Mm BWG Seamless Titanium Pipe Shell Heat Exchanger 4
