Titanium Heat Exchanger Tubes
>
|
| Place of Origin | Changzhou |
| Brand Name | Joyruns |
| Certification | ISO9001 |
| Model Number | 38.1*1.5MM |
ASTM B861/ASME SB861 GR.2 Seamless Titanium and Titanium Alloy Pipes
ASME SB-861 is the standard specification for titanium and titanium seamless pipes which are intended for general corrosion-resisting and elevated temperature service. It is almost identical to ASTM B861 except for an editorial revision to para. 4.1.10. It covers 34 grades of titanium and titanium alloys.
The ASME SB-861 (ASTM B861) includes many necessary contents: 34 grades of Ti and Ti alloys, referenced documents, terminology, ordering information, manufacture, chemical requirements, dimensions of pipe, tensile requirements, tolerances and variations, surface finish, inspection and tests, packing and certification, etc.
Titanium tube widely used in electrical equipment, salt-making equipment, ocean anti-corrosion, petroleum drilling equipment, heat exchanger, condenser, heater distiller, evaporator
Titanium Grade 1 Pipes & Tubes are the gentlest titanium having the mix of specific traits like most elevated pliability, great cool formability and a superb resistance from mild to high oxidization. These Titanium Grade 1 Pipes & Tubes are showed as seamless pipes & welded pipes.
Chemical Composition of ASME SB861 Ti Seamless Pipe
|
Grade |
C |
N |
O |
H |
Ti |
V |
Al |
Fe |
|
Titanium Grade 1 |
.08 Max |
.03 Max |
.18 Max |
.015 Max |
Bal |
|
|
.20 Max |
|
Titanium Grade 2 |
0.1 max |
0.03 max |
0.25 max |
0.015 max |
99.2 min |
|
|
0.3 max |
Physical properties
| Grade | Tensile Strength (min) | Yeild strength (min) | Elongation(%) | ||
| Ksi | MPa | Ksi | MPa | ||
| Gr.1 | 35 | 240 | 20 | 138 | 24 |
| Gr.2 | 50 | 345 | 40 | 275 | 20 |
