Titanium Heat Exchanger Tubes
>
|
|
| Place of Origin | Changzhou |
| Brand Name | Joyruns |
| Certification | ISO9001 |
| Model Number | 16*1MM |
ASTM B337 Gr.1 Titanium tubes are typically used in commercial heat exchangers
Titanium Pipe and Seamless Tubes are made up of different grades of titanium alloys. There are commercially pure grades of titanium and alloyed grades. Navstar Steel is a leading manufacturer and supplier of Titanium Pipe in different grades and dimensions. The specifications for the titanium pipes are ASTM B337 and ASTM B338. Titanium is naturally strong and corrosion-resistant. The titanium oxide which forms on the surface avoids further oxidation.
Titanium tube widely used in electrical equipment, salt-making equipment, ocean anti-corrosion, petroleum drilling equipment, heat exchanger, condenser, heater distiller, evaporator
Titanium Grade 1 Pipes & Tubes are the gentlest titanium having the mix of specific traits like most elevated pliability, great cool formability and a superb resistance from mild to high oxidization. These Titanium Grade 1 Pipes & Tubes are showed as seamless pipes & welded pipes.
Chemical Composition of ASME SB337 Ti Seamless Pipe
| Grade | C | N | O | H | Ti | V | Al | Fe |
| Titanium Grade 1 | .08 Max | .03 Max | .18 Max | .015 Max | Bal | .20 Max | ||
| Titanium Grade 2 | 0.1 max | 0.03 max | 0.25 max | 0.015 max | 99.2 min | 0.3 max | ||
| Titanium Grade 4 | .08 Max | .05 Max | .40 Max | .015 Max | Bal | .50 Max | ||
| Titanium Grade 5 | 0.10 max | 0.05 max | 0.20 max | 0.015 max | 90 min | 3.5-4.5 | 5.5-6.75 max | 0.40 max |
| Titanium Grade 7 | .08 Max | .03 Max | .25 Max | .015 Max | Bal | .30 Max | ||
| Titanium Grade 9 | .08 Max | .03 Max | .15 Max | .015 Max | - | .25 Max | ||
| Titanium Grade 12 | .08 Max | .03 Max | .25 Max | 0.15 Max | - | .30 Max |
Physical properties
| Grade | Tensile Strength (min) | Yeild strength (min) | Elongation(%) | ||
| Ksi | MPa | Ksi | MPa | ||
| Gr.1 | 35 | 240 | 20 | 138 | 24 |
| Gr.2 | 50 | 345 | 40 | 275 | 20 |
