Product Details:

Place of Origin: Changzhou
Brand Name: Joyruns
Certification: ISO9001
Model Number: 6mm to 88.9mm

Payment & Shipping Terms:

Minimum Order Quantity: 2Tons
Packaging Details: wooden box packing
Delivery Time: 20days
Payment Terms: L/C, T/T
Supply Ability: 1500Tons/Month
Get Best Price Contact Now

Detail Information

Standard: ASTM B111, DIN1785,JIS H3300,BS 2871 CZ110 Material: C68700/CuZn20AL2/CZ110/C71000
OD Size: 6mm To 89mm WT: 0.7mm To 3mm
Length: 12m Type Of Productis: Seamless Tube, Welded Tube , Copper Fin Tube
High Light:

C71640 Copper Nickel Tube

,

Carbon Steel Seamless Tubes C71640

,

B111 Carbon Steel Seamless Tubes

Product Description

ASTM B111 C71640 Copper Nickel Tube for heat exchanger applications



66-30-2-2 Cu-Ni (C71640, CW353H) Tube is a modified version of 70-30 alloy tube and contains 2% iron and 2% Mn and can withstand higher flow rates than 90-10 and 70-30. The other important note is that it has slightly less resistance to localized corrosion. These C71640 products are mainly used as condenser tubing. Commercially, UNS C71640 condenser tubes are mainly in demand by Industrial Plants. It was originally developed for higher resistance to erosion-corrosion in the presence of suspended solids and has been extremely successful in multi-stage flash desalination plants, particularly in the heat rejection and brine heater sections.





Steel Grade

Cu Sn Al As Ni Fe Mn Pb Zn
C70400 Remain - - - 4.8-6.2 1.3-1.7 0.3-0.8 0.05 max 1.0 max
C70600 Remain - - - 9.0-11.0 1.0-1.8 1.0 max 0.05 max 1.0 max
C71500 Remain - - - 29.0-33.0 0.4-1.0 1.0 max 0.05 max 1.0 max
C71640 Remain - - - 29.0-32.0 1.7-2.3 1.5-2.5 0.05 max 1.0 ma



Steel Grade Temper Tensile Strength Mpa Yield Strength Mpa

Elongation

%

Expansion

Requirement

%

Grain Size

mm

    Min Min Max Min Min Min Max
C70400 061 260 85 - - 30 0.01 0.045
  H55 275 205 - - 20 - -
C70600 061 275 105 - - 30 0.01 0.045
  H55 310 240 - - 20 - -
C71500 061 360 125 - - 30 0.01 0.045
  HR50A 495 345 - 12 20 - -
  HR50B 495 345 - 15 20 - -
C71640 061 435 170 - - 30 0.01 0.045
  HR50 560 400 - - 20 - -





Packing

ASTM B111 C71640 Copper Nickel Tube Heat Exchanger Carbon Steel Seamless Tubes 0   ASTM B111 C71640 Copper Nickel Tube Heat Exchanger Carbon Steel Seamless Tubes 1   ASTM B111 C71640 Copper Nickel Tube Heat Exchanger Carbon Steel Seamless Tubes 2





ASTM B111 C71640 Copper Nickel Tube Heat Exchanger Carbon Steel Seamless Tubes 3
