EN10216-2 Heat Exchanger Steel Tube P265GH Cold Drawing High Pressure Stainless Steel Tube

EN10216-2 Heat Exchanger Steel Tube P265GH Cold Drawing High Pressure Stainless Steel Tube

Product Details:

Place of Origin: CHANGZHOU, CHINA
Brand Name: Joyruns
Certification: ISO9000
Model Number: 1/2” to 16”

Payment & Shipping Terms:

Minimum Order Quantity: 5 tons per size
Price: Negotiable
Packaging Details: Plastic packing, oiling, wooden box
Delivery Time: 30DAYS
Payment Terms: TT OR LC
Supply Ability: 5000T PER MONTH
Get Best Price Contact Now

Detail Information

Standard: EN10216-2 Grade: P235GH, P265GH, 20Mn, 16Mo3,15CrMo
OD. Range: 6mm – 137mm Wall Thickness: 1mm-20m
Length: Max Length 12M Type: Seamless Boiler Tube
High Light:

P265GH Heat Exchanger Steel Tube

,

EN10216-2 Heat Exchanger Steel Tube

,

P265GH High Pressure Stainless Steel Tube

Product Description

EN10216-2 P265GH Cold drawing seamless steel tube for higher pressure



EN10216-2 P265GH steel pipeline is widely used in petrochemical, oil and natural gas industries. P235GH pipe is normalized carbon alloy steel. The chemical properties of the P235GH tube are typical, in which Mo 0.08% max and Cr 0.30% max are added.



EN10216-2 P265GH steel pipeline is a flat product of pressure steel (weldable high-temperature performance of alloy and alloy steel) manufactured by German and European standard DIN EN 10216, which EN10216-2 P265GH steel pipeline is used to manufacture pressure vessels, boilers and heat exchangers, steam pipes and pressure vessels.



Specifications:

Grade and Chemical Composition ( % ) and mechanical property


Standard


Grade


Chemical Composition


Mechanical Property

C

Si

Mn

P≤

S≤

Cr≤

Mo

Tensile Strength
(MPa)

Yield Strength
(MPa)

Elongation

L

t

EN10216-2

195GH

≤ 0.13

≤ 0.35

≤ 0.70

0.025

0.020

0.30

≤ 0.08

320~440

≥ 195

≥ 27

≥ 25

P235GH

≤ 0.16

≤ 0.35

≤ 1.20

0.025

0.020

0.30

≤ 0.08

360~500

≥ 235

≥ 25

≥ 21

P265GH

≤ 0.20

≤ 0.40

≤ 1.40

0.025

0.020

0.30

≤ 0.08

410~570

≥ 265

≥ 23

≥ 20

20MnNb6

≤ 0.22

0.15~
0.35

1.00~ 1.50

0.025

0.020

-

-

500~650

≥ 355

≥ 22

≥ 20

16Mo3

0.12~
0.20

≤ 0.35

0.40~ 0.90

0.025

0.020

0.30

0.25~
0.35

450~600

≥ 280

≥ 22

≥ 20





EN10216-2 Heat Exchanger Steel Tube P265GH Cold Drawing High Pressure Stainless Steel Tube 0  EN10216-2 Heat Exchanger Steel Tube P265GH Cold Drawing High Pressure Stainless Steel Tube 1   EN10216-2 Heat Exchanger Steel Tube P265GH Cold Drawing High Pressure Stainless Steel Tube 2



EN10216-2 Heat Exchanger Steel Tube P265GH Cold Drawing High Pressure Stainless Steel Tube 3  EN10216-2 Heat Exchanger Steel Tube P265GH Cold Drawing High Pressure Stainless Steel Tube 4  EN10216-2 Heat Exchanger Steel Tube P265GH Cold Drawing High Pressure Stainless Steel Tube 5



EN10216-2 Heat Exchanger Steel Tube P265GH Cold Drawing High Pressure Stainless Steel Tube 6
