Stainless Steel Condenser Tube
>
|
|
| Place of Origin | CHANGZHOU, CHINA |
| Brand Name | Joyruns |
| Certification | ISO9000 |
| Model Number | 6mm to 600mm |
ASTM A213/A213M-17 Seamless Alloy-Steel Boiler, Superheater, and Heat-exchanger Tubes
Standard: ASTM A213/ASME SA213, testing according to ASTM A450/ASME SA450
Application: This type of tube is widely used for shell & tube bundle heat-exchanger, condenser, boiler, superheaters
OD: 3.2-76.2 mm
WT:1-15 mm
Length: 25 meters(Max)
Remarks: 19.05 X 2.11(MWT), 25.4 X 2.77MWT) are common size.
Fabricating process: Seamless & Cold rolled
Heat treatment: Solution
Non-destructive test: 100% Eddy Current Test
Package: Bundle package or plywood box
|
Standard |
Grade |
钢号 |
Chemical Composition% |
|||||||
|
C |
Mn |
P |
S |
Si |
Ni |
Cr |
Mo |
|||
|
ASTM A213 |
TP304 |
S30700 |
≤0.08 |
≤2.00 |
≤0.040 |
≤0.030 |
≤0.75 |
8.00-11.0 |
18.0-20.0 |
/ |
|
TP304H |
S30409 |
0.04-0.10 |
≤2.00 |
≤0.040 |
≤0.030 |
≤0.75 |
8.00-11.0 |
18.0-20.0 |
/ |
|
|
TP316 |
S31600 |
≤0.08 |
≤2.00 |
≤0.040 |
≤0.030 |
≤0.75 |
11.0-14.0 |
16.0-18.0 |
2.00-3.00 |
|
|
TP316L |
S31603 |
≤0.035 |
≤2.00 |
≤0.040 |
≤0.030 |
≤0.75 |
10.0-15.0 |
16.0-18.0 |
2.00-3.00 |
|
|
TP321 |
S32100 |
≤0.08 |
≤2.00 |
≤0.040 |
≤0.030 |
≤0.75 |
9.00-13.0 |
17.0-20.0 |
/ |
|
|
TP321H |
S32109 |
0.04-0.10 |
≤2.00 |
≤0.040 |
≤0.030 |
≤0.75 |
9.00-13.0 |
17.0-20.0 |
/ |
|
|
TP347 |
S34700 |
≤0.08 |
≤2.00 |
≤0.040 |
≤0.030 |
≤0.75 |
9.00-13.0 |
17.0-20.0 |
/ |
|
|
TP347H |
S34709 |
0.04-0.10 |
≤2.00 |
≤0.040 |
≤0.030 |
≤0.75 |
9.00-13.0 |
17.0-20.0 |
/ |
|
| Standard | Grade | 钢号 | Chemical Composition% | ||
| Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | |||
| ASTM A213 | TP304 | S30700 | ≥515 | ≥205 | ≥35 |
| TP304H | S30409 | ≥515 | ≥205 | ≥35 | |
| TP316 | S31600 | ≥515 | ≥205 | ≥35 | |
| TP316L | S31603 | ≥485 | ≥170 | ≥35 | |
| TP321 | S32100 | ≥515 | ≥205 | ≥35 | |
| TP321H | S32109 | ≥515 | ≥205 | ≥35 | |
| TP347 | S34700 | ≥515 | ≥205 | ≥35 | |
| TP347H | S34709 | ≥515 | ≥205 | ≥35 | |
