EN10139 DC04 6*0.6MM Cold Rolled Single Wall Steel Bundy Tube
|Place of Origin:||Changzhou|
|Model Number:||4.76*0.5,4.76*0.6, 4.76*0.7, 6*0.6, 6*0.7,8*0.6|
Payment & Shipping Terms:
|Minimum Order Quantity:||2Tons|
|Packaging Details:||wooden box packing, pallet packing|
|Payment Terms:||L/C, T/T|
|Techincal:||Welded Bundy Coil Tube||Grade:||DC04, BHG1, BHG2, SPCC|
|Surface Type:||Bright, Copper Coated, Zinc Coated||Usage:||Refrigetor, Wire On Tube Condenser, Evaporator|
|Tube Diameter:||4.76mm, 6mm, 6.35mm,8mm, 10mm||Wall Thickness:||0.5mm, 0.55mm, 0.6mm, 0.65mm,0.7mm,0.8mm|
Bundy Steel Tube EN10139 DC04 6*0.6MM Cold Rolled Single Wall Copper coated coil tube Applied for Conderser
1. Main use: widely used in evaporators, refrigerators, automobiles and heaters
2. Features: high intensity, good plasticity, and small resistance
3. Standard: ASTMA254-94
4. Materials: materials can be altered according to customers' requirements
5. Size: 4.7*0.7mm, 6.35*0.7mm,
6. Type: Zinc coating outer side, Cu coating outer side, Cu coating both sides
7. Packing: packed with iron pallet
color Bundy tube /single wall Bundy tube/Coating Bundy tube
Single wall Bundy tube for condenser
Outer diameter: 4.0mm-10.0mm.
Wall thickness: 0.5mm-1.0mm.
Single wall Bundy tube for Condenser.
We supply steel tubes of many sizes with fine accuracies, made from low carbon steel strips.
Single wall steel tubing is the most common type of tubing used in household refrigeration applications. Bundy single wall tubing is manufactured by continuously forming a single low carbon steel strip into a tubular shape and welding the adjoining edges using a high-frequency induction welding process. Through strict process controls, the internal weld bead is held to a minimum and all external flashing is removed. Corrosion-resistant coatings are applied inline to assure uniform coverage.
Dimensions and Tolerances
SINGLE WALL STEEL TUBING OD & WT TOLERANCE
All the tube diameters can be available plain, zinc-coated or copper coated.
The plain tube is supplied with its outside surface slightly oiled to improve the resistance to oxidation. The tube shall be kept in dry storages, away from air drafts, humidity or any other corrosive agents
ELECTROLYTIC BOTH SIDE COPPER COATING
The steel strip from which the tube is made shall be copper coated on both sides with a copper layer ≥2µm. The area along the welding seam, on the outside surface is not coated because of the scarfing operation to remove the excessive bead.
HOT-DIP ZINC COATING
Tube outside surface can be coated with a layer of zinc whose weight is ≥ 70 grams per square meter determined by UNI EN ISO 1460/97. This coating the tube withstands to > 72 h in salt spray fog test before showing red rust (according to UNI ISO 9227).
Laboratory Testing Equipment
