EN10216-2 Seamless Alloy Steel Tube P235GH Cold Drawn Pipe, 88.9mmOD
  • EN10216-2 Seamless Alloy Steel Tube  P235GH Cold Drawn Pipe, 88.9mmOD
  • EN10216-2 Seamless Alloy Steel Tube  P235GH Cold Drawn Pipe, 88.9mmOD
  • EN10216-2 Seamless Alloy Steel Tube  P235GH Cold Drawn Pipe, 88.9mmOD
  • EN10216-2 Seamless Alloy Steel Tube  P235GH Cold Drawn Pipe, 88.9mmOD
  • EN10216-2 Seamless Alloy Steel Tube  P235GH Cold Drawn Pipe, 88.9mmOD

EN10216-2 Seamless Alloy Steel Tube P235GH Cold Drawn Pipe, 88.9mmOD

Place of Origin Changzhou
Brand Name Joyruns
Certification ISO9001
Model Number 6mm --137mm
Product Details
Standard:
DIN2391, EN10305, EN10216, EN10210,EN10083-3
Material:
SAE4140, 42CrMo4, CK45,E235C,ST35
OD SIZE:
6MM--137MM
WT:
1MM--30MM
Length:
According Customer
Divery Condition:
+BK,+C,+NBK,+QT,+N,+LC
High Light:

EN 10216-2 Seamless Alloy Steel Tube

,

42CrMo4 Seamless Alloy Steel Tube

,

30MM Cold Drawn Pipe

Product Description

EN 10216-2 P 235 GH Cold drawing Alloy steel tube

EN Specification alloy steel Tubes are used for high-temperature service applications. Seamless Alloy Steel Tubes according to EN 10216-2 Grade P235GH are reheated and furnished in full annealed, isothermal annealed, or normalized quenched and tempered condition.EN 10216-2 Grade P235GH Alloy Steel Seamless Tubes have a typical chemistry with additions of max 0.30 Chromium and max 0.08 Molybdenum. Bearing minimum tensile strength of 360 Mpa and maximum tensile strength of 500 Mpa, EN 10216-2 Grade P235GH Tubes have a minimum yield strength of 235 Mpa.

Chemistry Composition

C, % Si, % Mn, % P, % S, % Cr, % Ni, % Cu, % Mo, % Nb, % Ti, % V, %
0.16 max 0.35 max 1.20 max 0.025 max 0.020 max 0.30 max 0.30 max 0.30 max 0.08 max 0.01 max 0.04 max

0.02 max



Mechanical Properties

Tensile Strength, MPa Yield Strength, MPa Elongation, %
360-500 235 min 25 min



Outside Diameter & Tolerance

Cold Drawn Outside Diameter, mm Tolerance
  OD≤114 ±0.5% or ±0.3mm



Wall thickness & Tolerance

Cold Drawn Outside Diameter, mm   Tolerance
  OD≤114   ±10% or ±0.2mm
