Product Details:

Place of Origin: CHANGZHOU, CHINA
Brand Name: Joyruns
Certification: ISO9000
Model Number: 6mm to 600mm

Payment & Shipping Terms:

Minimum Order Quantity: 5 tons per size
Price: Negotiable
Packaging Details: Plastic packing, oiling, wooden box
Delivery Time: 30DAYS
Payment Terms: TT OR LC
Supply Ability: 5000T PER MONTH
Get Best Price Contact Now

Detail Information

Length: Max Length 24M Type: Seamless And Welded Austenitic Stainless Steel Pipe
OD. Range: 6mm – 600mm Grade: TP304/SUS304/SUS306
Wall Thickness: 1mm-40mm Standard: ASTM (ASME) A213/JIS3448
High Light:

JIS3448 Stainless Steel Condenser Tube

,

SUS304 Stainless Steel Condenser Tube

,

stainless steel heat exchanger tubes SUS304

Product Description

SUS304 JIS3448 Cold drawing Seamless Stainless Steel Pipe

Stainless steel pipes for general piping (JIS G 3448) are standardized for building equipment piping (water supply, hot water supply, drainage, cold/hot water, firewater, and other piping), and are thinner than conventional stainless steel pipes. It is characterized by four types: SUS304, SUS315J1, SUS315J2, and SUS316.
It is recommended that the operating pressure be set to 2MPa or less in view of the consistency of the pressure resistance performance of the joint system.



Standard: JIS G3448

Austenitic Steel: SUS 304 TPD, SUS 315J1TPD, SUS315J2TPD, SUS316TPD



Chemical composition

Type symbol C Si Mn P S Ni Cr Mo Cu
SUS304TPD 0.08 or less 1.00 or less 2.00 or less 0.045 or less 0.030 or less 8.00-10.50 18.00-20.00 ―A) ―A)
SUS315J1TPD 0.5-2.50 8.50-11.50 17.00-20.50 0.50-1.50 0.50-3.50
SUS315J2TPD 2.50-4.00 11.00-14.00 17.00-20.50 0.50-1.50 0.50-3.50
SUS316TPD 1.00 or less 10.00-14.00 16.00-18.00 2.00-3.00 ―A)
